4 Pole RCD Circuit Breaker 415V 63A 3 Phase Circuit Breaker
Product Description:
Electrical Features:
| Mode | Electromagnetic |
| Type(wave form of the earth leakage sensed): | B |
| Rated current In | 25,,40A,63A |
Poles | 4P |
Rated voltage | 4P 415V~ |
Insulation voltage Ui | 500V |
Rated frequency | 50/60Hz |
Rated residual operation current(I△n) | 30mA |
Rated residual making and breaking capacity (I△m) | 500(In=2540A) 630(In=63A) |
Short-circuit current Inc= I△c | 10,000A |
Break time under I△n | ≤0.1s |
Rated impulse withstand voltage(1.5/50) Uimp | 4000V |
Dielectric test voltage at ind.Freq. for 1min | 2.5kV |
Electrical life | 2,000 Cycles |
Mechanical life | 4,000 Cycles |
Installation:
| Contact position indicator | Yes |
| Protection degree | IP20 |
| Ambient temperature(with daily average≤35°C) | -5°C~+40°C |
| Storage temperature | -25°C~+70°C |
| Terminal connection type | Cable/Pin-type busbar/U-type busbar |
| Terminal size top/bottom for cable | 35mm2 18-3AWG |
| Terminal size top/bottom for busbar | 35mm2 18-3AWG |
| Tightening torque | 2.5Nm 22In-lbs |
| Mounting | On DIN rail EN60715(35mm) by means of fast clip device |
| Connection | Power supply in both directions |
FAQ:
Q1. What about the lead time?
A: 10-15 days for mass production.
Q2. How do you ship the goods and how long does it take to arrive?
A: Ship by DHL, UPS, FedEx or TNT. It takes 7-10 days to arrive.
Airline and sea shipping also optional.
Q3. How to proceed an order for EV charging cables?
A: 1) let us know your requirements or application.
2) We quote according to your requirements or our suggestions.
3) Customer confirms the samples and places deposit for formal
order.
4) We arrange the production.
Q4. Is it OK to print my logo on the products?
A: Yes. Please inform us formally before our production.
Q5: Do you offer guarantee for the products?
A: Yes, we offer 1 year warranty to our products.
Q6: How to deal with the faulty?
A: 1)Our products are produced in strict quality control system and
the defective rate will be less than 0.5%.
2)During the guarantee period, we will send new one with new order
for small quantity. For defective batch products, we will repair
them and resend them to you or we can discuss the solution
including re-call according to real situation.
