IEC Type 2 7KW AC Electric Vehicle Charger Portable Ev Charging Station 3 Phase 32A

Chengdu Heiu Technology Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap IEC Type 2 7KW AC Electric Vehicle Charger Portable Ev Charging Station 3 Phase 32A from wholesalers

    Buy cheap IEC Type 2 7KW AC Electric Vehicle Charger Portable Ev Charging Station 3 Phase 32A from wholesalers
    • Buy cheap IEC Type 2 7KW AC Electric Vehicle Charger Portable Ev Charging Station 3 Phase 32A from wholesalers
    • Buy cheap IEC Type 2 7KW AC Electric Vehicle Charger Portable Ev Charging Station 3 Phase 32A from wholesalers
    • Buy cheap IEC Type 2 7KW AC Electric Vehicle Charger Portable Ev Charging Station 3 Phase 32A from wholesalers
    • Buy cheap IEC Type 2 7KW AC Electric Vehicle Charger Portable Ev Charging Station 3 Phase 32A from wholesalers

    IEC Type 2 7KW AC Electric Vehicle Charger Portable Ev Charging Station 3 Phase 32A

    Ask Lasest Price
    Brand Name : HEIU
    Model Number : T2-CEE-32A
    Certification : TUV,CE,RoHS
    Price : negotiable
    Payment Terms : T/T, L/C, Western Union
    Supply Ability : 1000pcs/Day
    Delivery Time : 10-15 days
    • Product Details
    • Company Profile

    IEC Type 2 7KW AC Electric Vehicle Charger Portable Ev Charging Station 3 Phase 32A


    IEC Charger Type 2 32A 3 Phase 7KW AC Electric Vehicle Charger Portable Ev Charging Station


    Highlights:

    Compact Car Charger
    The charge cable measures 5m from plug to plug. It is a compact portable EV charging station that is an ideal solution for low-cost charging in your garage or to keep in the trunk of your EV for charging at work or on trips.

    Over Temperature Protection
    When the internal temperature of the control box exceeds 85°C, enter over-temperature protection, and stop charging. It will recover charging after the temperature drops to 65°C.
    Detailed LED Display
    Easily read the charging temperature, current, time and power status in kWh on the convenient screen.
    High Security
    Our EV charger adopts High Strength ABS material, which has better quality and high durability. Our chargers have over-current protection, over-voltage protection, under-voltage protection, leakage protection, and overheating protection.
    Applicable Vehicles
    There are two different charging standards for EVs, Type 1 for US and Type 2 for EU. Please make sure you are choosing the correct charging plug for your EV.


    Characteristic:


    GeneralBrand: HEIU
    Type: Electric Car Charger
    Color: Black
    SpecificationService life: >10000 times
    Insulation resistance: > 1000M ohm
    Terminal temperature rise: <50K
    Withstand voltage: 2000V
    Contact impedance: 0.5mohm
    Max Vibration resistance: Meet JDQ 53.3 requirements
    Working temperature: -30°C ~ 50°C
    Shell Material: Thermo Plastic (Insulator inflammability UL94 V0)
    Contact Pin: Copper alloy, silver
    Sealing gasket: Rubber
    Inlet cable spec: 3*2.5mm2
    Outlet cable spec: 3*2.5mm2 2*0.5mm2
    Cable diameter: 12(mm) / 0.47(in)
    Certificate: TUV/ RoHs
    Power plug: CEE 3Pins
    EV charging plug: Type 2 or type 1
    Current: 10A 16A 20A 24A 32A adjustable
    Voltage: AC 110V-250V
    Power: max 7.4 kw
    Length: 5m (16.4ft)
    Cable: Black straight cable
    Controller type: LCD screen
    Protection level: IP66
    SizeProduct Size(L): 5m
    Package Size(L x W x H): 34 x 35 x 12 cm

    Images:



    Factory Tour:



    Why Heiu:



    Quality IEC Type 2 7KW AC Electric Vehicle Charger Portable Ev Charging Station 3 Phase 32A for sale
